In the US there has been a lot of discussion about the federal budget. Cuts to NIH, NSF, CDC, and everything else seems to be about shoring up the budget to remove $1,000,000,000,000 - $1 trillion - from an $8.3 trillion budget (this doesn’t include interest on the debt). The NYT has been using “waffle charts” to depict the budget in their reporting. Here’s an example from an April 13th article in the UpShot titled, “Why Elon Musk Hasn’t Come Close to Finding $1 Trillion in Cuts”.

My impression has been that going after the NIH and NSF has been like trying to find $100 by searching for lost coins in my couch. Throughout the article they provide a series of aggregated waffle charts to show what different types of cuts might look like. I can imagine another article with an interactive visualization that would allow the user to find the $1 trillion.

A waffle chart is also called a “square pie chart”. That’s fair. Each square represents a consistent value. In this case, it’s $5 billion. One problem with pie charts is that it’s really difficult to interpret the relative area of a wedge from a circle. In contrast, a waffle chart deals in squares, which can be counted to make comparisons between groups easier. What do you think of this alternative?

Anyway, how would we make this in R? One thought would be that these are effectively heat maps with a few specific fill colors for each group. It would take some logic to figure out how to make specific tiles in the heat map the same group and preferably to have those tiles be arranged next to each other. Thankfully, there’s a package for that {waffle}.

Looking through the {waffle} package’s GitHub documentation, I see a lot to like. Instead of squares, you could also use icons like pizza pieces, slices of bread, or apples. You can also compile multiple waffle charts with facet_wrap() or iron(). Here’s an example that I would riff off of to recreate the NYT waffle chart:

library(hrbrthemes)
library(waffle)
library(tidyverse)
tibble(
  parts = factor(rep(month.abb[1:3], 3), levels=month.abb[1:3]),
  values = c(10, 20, 30, 6, 14, 40, 30, 20, 10),
  fct = c(rep("Thing 1", 3), rep("Thing 2", 3), rep("Thing 3", 3))
) -> xdf
ggplot(
  data = xdf,
  aes(fill=parts, values=values)
) +
  geom_waffle(
    color = "white",
    size = 1.125,
    n_rows = 6
  ) +
  facet_wrap(~fct, ncol=1) +
  scale_x_discrete(
    expand = c(0,0,0,0)
  ) +
  scale_y_discrete(
    expand = c(0,0,0,0)
  ) +
  ggthemes::scale_fill_tableau(name=NULL) +
  coord_equal() +
  labs(
    title = "Faceted Waffle Geoms"
  ) +
  theme_ipsum_rc(grid="") +
  theme_enhance_waffle()

How would I adapt this code for my use?

First, I notice that the NYT version has partial squares on the bottom row of the charts. The area of those are difficult to interpret, so I’d forgo those and instead use full squares in my version of the waffle chart. This would result in the bottom row not having all 50 squares across.

Second, each waffle chart has its own title and in some cases, subtitle. I’d likely use {ggtext} to alter the facet titles to have a bolded title and regular font subtitle. I’d also like to make the subtitle font a smidge smaller than the facet title. If I can’t do this, then I might opt to use {patchwork} instead of facet_wrap() giving each plot its own title and subtitle and then the overall plot a title. I’d like to avoid {patchwork} because I can foresee a lot of duplicated code since each facet will require very similar code.

Third, each waffle chart also has text indicating the percent cut on the right side of the title. I’d likely do this with geom_text(). Since it would be positioned outside the plotting panel, I’d need to use coord_cartesian(clip = "off").

Finally, I’ve had a bit of a journey to find the data, but I think this PDF from the Congressional Budget Office (CBO) has the data we want in the 2026 column.

​
