For this week, I’d like to share with you a newsletter that I subscribe to from Philip Bump of the Washington Post. Each week he explores some data using a variety of visualizations and also provides critiques about visualizations he’s found online. Earlier this week his newsletter talked about the success of different seeds in the men’s NCAA basketball tournament. Further into the newsletter he described a “bivariate choropleth plot” showing the correlation between drinking and smoking levels within each county across the US. Those maps are cool. But I (and I think Bump also) find them a bit difficult to decipher. Choropleth plots suffer from the instinct to assume that counties with large land area also have many people. This is very much not true.

For his take, he used data from the University of Wisconsin’s Population Health Institute (UWPHI). The UWPHI has data on many variables related to health - including smoking and drinking - for each county. Here was his version of the bivariate choropleth plot rendered as a scatter plot:

The five-digit numbers aren’t zip codes, they are FIPS codes. The first two digits indicate the state and the other digits the county in the state.

What stands out to you about this visualization? What correlation do you see between the two variables? What questions do you have about the relationship? About how to make the plot? What would you like to learn to implement in R? What do you already feel comfortable executing?

Again, this is a scatter plot. My assumption is that when we download the data from UWPHI we’ll get a data frame that we can simplify to three columns - the FIPS code, the percent of smokers, and the percent of drinkers or the number of drinks in some time period. Once we have it in this format we can map the drinking metric to the x aesthetic and the smoking metric to the y aesthetic. We can generate the scatter plot using geom_point().

Second, there are clearly a finite number of possible values since the data already appear to be discretized. This causes a lot of over plotting of the data. I notice that the points are different shades of green. No doubt the more intense shade is where there’s more overlap. We could pull this off by using the alpha aesthetic in geom_point(). This aesthetic controls the transparency of the point. If we use alpha = 0.20 then the plotting symbol will be 80% transparent. If there are 5 points on top of each other, then the symbol will be opaque.

Third, there is a fitted line through the data. We can pull this off using geom_smooth(). We can get a polynomial or straight line with this function. To get the straight line, we’ll use method = "lm" as an argument. We’ll also want to turn off the cloud indicating the standard error. He doesn’t provide the correlation coefficient and I wonder if it is significantly different from zero.We could easily calculate and test the coefficient using corr.test().

Fourth, he creates four quadrants that roughly align with the bivariate nature of the choropleth plot. We could achieve this by drawing light gray horizontal and vertical lines that intersect at the median smoking and drinking levels. Then we could use annotate() to add the bolded descriptions that he included.

Finally, around the outside of the cloud of points he includes 20 solid green points with their FIPS codes. I would implement this in three steps. First, I’d use filter() to get the desired FIPS codes. Second, I’d use the filtered data with geom_point() using alpha = 1 to get the solid symbols. I notice that those symbols have a black edge telling me that we’d want to use shape = 21. Third, I’d use geom_text() with the filtered data to label the points. I’d add nudge_x and nudge_y columns to the filtered data to indicate which way to bump the label for each of these points. You might forgive me if instead of using his points of interest I were to denote the data for counties in Michigan (FIPS codes starting with 26)

Along the way there are other interesting things we’d want to implement in this figure. Those include removing the x and y-axis text and ticks and customizing the placement of the x and y-axis titles. A more advanced move would be to think about how we might make a function to automatically generate this type of figure for any pair of data columns in the UWPHI dataset.
